AMSCO® Century® Small Steam Sterilizer

Equipment Considerations

AMSCO® Century® Small Steam Sterilizer model numbers include, but may not be limited to: G-116, G-120, V-116 and V-120.

Utility Requirements

See the Technical Specifications tab for more info.

Need help identifying a part?

Chat with Parts ID

Need help identifying a part?

Chat with Parts ID

Resources

Operator Manuals

Parts List

Maintenance Requirements Technical Specifications

Preventative Maintenance Packs

Printer Supplies

Frequently Purchased Parts

Parts List

Equipment Parts List

Add to Cart

Add to List

Proceed to checkout for contracted price

Maintenance Requirements

Page Title

PREVENTIVE MAINTENANCE FOR AMSCO® CENTURY® SMALL STEAM STERILIZER

Reduce equipment downtime and stay compliant.

PREVENTIVE MAINTENANCE REQUIREMENTS

Annual Inspections	2
Inspection Intervals	Semi-Annual
Inspection Requiring Parts	1

PARTS

Review the information below to find the PM parts you need for your equipment by required inspection. The PM parts required are available in a parts-only pack and a Parts & Labor (PL) kit. PL kits are an all-in-one pricing option that includes all the required annual preventive maintenance parts for the equipment and professional labor installation of the parts. Select a SKU to learn more about what’s included and order online.

Jump to : Inspection 1 Inspection 2

INSPECTION 1

Model	Parts Only	Parts and Labor
For single-door units:	KIT PM PACK CEN SM STM SD P764336517	PL KIT FOR CENTURY 16" & 20" STM SD PL1010010
For double-door units:	KIT PM PACK CEN SM STM DD P764336518	PL KIT FOR CENTURY 16" & 20" STM DD PL1020010

INSPECTION 2

No additional parts are required for this inspection.

Page Title

ROUTINE MAINTENANCE FOR AMSCO® CENTURY® SMALL STEAM STERILIZER

Completing routine maintenance helps to ensure equipment is maintained correctly and reduces equipment downtime. For a complete list of recommended maintenance for this equipment, please reference yourOperator Manual.

CHECK EVERY INSPECTION

Jump to : Door Assembly Valves Piping Components Control

DOOR ASSEMBLY

Verify proper door and door proximity switch operation, adjusting the switch if needed. Check the condition of the door gasket for wear and tear and verify property tension on the power cable. For double-door units, check each door.

16 IN. DOOR COVER ASSEMBLY	P146657846	Add to cart
20 IN. DOOR COVER ASSEMBLY	P146657847	Add to cart
16. IN. DOOR SEAL	P146660159	Add to cart
DOOR SEAL 20X20 CENTURY	P146660160	Add to cart
BLOCK DOOR FRAME CATCH	P030440051	Add to cart
CABLE DOOR DRIVE	P093918039	Add to cart
DOOR SENSOR BRACKET	P093918191	Add to cart

VALVES

Verify valves for operation, check for leaks, and rebuild or replace as needed.

STEAM CONTROL VALUE ASM	P136809750	Add to cart
VALUE SOLENOID (WATER)	P764323548	Add to cart
VALVE FLO CONTROL (1GPM)	P049337091	Add to cart
VALVE SAFETY 100# S/S	P764316742	Add to cart
VALVE SAFETY ½ IN.	P764323459	Add to cart
SAFETY VALVE TUV/ASME	P093918511	Add to cart

PIPING COMPONENTS

Inspect strainers (including the steam, water, and jacket strainers) for debris and clean as needed. Verify proper operation and ensure there are no leaks.

STRAINER	P047708091	Add to cart
STRAINER ASSEMBLY	P093918035	Add to cart
GAUGE PRESSURE 0-100 PSI	P007871051	Add to cart
GAUGE-PRESSURE 0-160 PSI	P764323430	Add to cart

CONTROL

Verify the proper operation of the parts, including printers, touch panels, batteries, buzzers, fans, and more. See full details in the Equipment Operator Manual.

PRINTER PAPER ESPON 2 PLY (BOX OF 3 ROLLS))	P150828420	Add to cart
PRINTER RIBBER (BOX OF 2 CARTRIDGES)	P150828440	Add to cart
RETAINER PAPER ROLL	P093918016	Add to cart
PRINTER HEADER ASSEMBLY	P093918051	Add to cart
SPOOL ASSEMBLY	P093918058	Add to cart
STUD SPOOL	P093918213	Add to cart
PRINTER-HEADER ASSEMBLY	P093922925	Add to cart
PRINTER PAPER (BOX OF 3 ROLLS)	P129362819	Add to cart
TAPE(DISC).SPOOL TAKE-UP	P129367593	Add to cart
CIRCUIT BOARD BATTERY ASM	P093939011	Add to cart

CHECK ONCE A YEAR

Jump to : Valves Piping Components Control Safety Testing

VALVES

Rebuild or replace check valves and safety valves. Rebuild manifolds.

REPAIR KIT STEAM MANIFOLD S1	P764326477	Add to cart
P.M. PACK WATER MANIFOLD	P764326619	Add to cart
MANIFOLD ASSY-WATER	P146657789	Add to cart
MANIFOLD ASSY-EXHAUST	P146657788	Add to cart
MANIFOLD ASSY-STEAM	P146657787	Add to cart
REPAIR KIT STEAM MANIFOLD S1	P764326477	Add to cart
STEAM CONTROL VALVE ASM	P136809750	Add to cart
VALVE SAFETY 100# S/S	P764316742	Add to cart
VALVE SAFETY ½ IN.	P764323459	Add to cart

PIPING COMPONENTS

Replace the air filter cartridge and rebuild the jacket trap.

	AIR FILTER ASM-1/2 IN. NPT	P093909592	Add to cart
	KIT STEAM TRAP REPAIR	P764080001	Add to cart

CONTROL

Replace the fan filter, check all service-settable valves in Service Test Mode, verify each valve's functional operation, and verify temperature and pressure settings according to the Maintenance Manual.

KIT FAN REPL CENT & EVOL

P755718039

Add to cart

SAFETY TESTING

Inspect the ground bond and connections to the sterilizer, including steam, water, and drain connections, and test ground continuity.

ROUTINE MAINTENANCE FOR AMSCO® CENTURY® SMALL STEAM STERILIZER

CHECK EVERY INSPECTION

Jump to : Door Assembly Valves Piping Components Control

DOOR ASSEMBLY

	16 IN. DOOR COVER ASSEMBLY P146657846 Add to cart
	20 IN. DOOR COVER ASSEMBLY P146657847 Add to cart
	16. IN. DOOR SEAL P146660159 Add to cart
	DOOR SEAL 20X20 CENTURY P146660160 Add to cart
	BLOCK DOOR FRAME CATCH P030440051 Add to cart
	CABLE DOOR DRIVE P093918039 Add to cart
	DOOR SENSOR BRACKET P093918191 Add to cart

VALVES

Verify valves for operation, check for leaks, and rebuild or replace as needed.

	STEAM CONTROL VALUE ASM P136809750 Add to cart
	VALUE SOLENOID (WATER) P764323548 Add to cart
	VALVE FLO CONTROL (1GPM) P049337091 Add to cart
	VALVE SAFETY 100# S/S P764316742 Add to cart
	VALVE SAFETY ½ IN. P764323459 Add to cart
	SAFETY VALVE TUV/ASME P093918511 Add to cart

PIPING COMPONENTS

Inspect strainers (including the steam, water, and jacket strainers) for debris and clean as needed. Verify proper operation and ensure there are no leaks.

	STRAINER P047708091 Add to cart
	STRAINER ASSEMBLY P093918035 Add to cart
	GAUGE PRESSURE 0-100 PSI P007871051 Add to cart
	GAUGE-PRESSURE 0-160 PSI P764323430 Add to cart

CONTROL

Verify the proper operation of the parts, including printers, touch panels, batteries, buzzers, fans, and more. See full details in the Equipment Operator Manual.

	PRINTER PAPER ESPON 2 PLY (BOX OF 3 ROLLS)) P150828420 Add to cart
	PRINTER RIBBER (BOX OF 2 CARTRIDGES) P150828440 Add to cart
	RETAINER PAPER ROLL P093918016 Add to cart
	PRINTER HEADER ASSEMBLY P093918051 Add to cart
	SPOOL ASSEMBLY P093918058 Add to cart
	STUD SPOOL P093918213 Add to cart
	PRINTER-HEADER ASSEMBLY P093922925 Add to cart
	PRINTER PAPER (BOX OF 3 ROLLS) P129362819 Add to cart
	TAPE(DISC).SPOOL TAKE-UP P129367593 Add to cart
	CIRCUIT BOARD BATTERY ASM P093939011 Add to cart

CHECK ONCE A YEAR

Jump to : Valves Piping Components Control Safety Testing

VALVES

Rebuild or replace check valves and safety valves. Rebuild manifolds.

	REPAIR KIT STEAM MANIFOLD S1 P764326477 Add to cart
	P.M. PACK WATER MANIFOLD P764326619 Add to cart
	MANIFOLD ASSY-WATER P146657789 Add to cart
	MANIFOLD ASSY-EXHAUST P146657788 Add to cart
	MANIFOLD ASSY-STEAM P146657787 Add to cart
	REPAIR KIT STEAM MANIFOLD S1 P764326477 Add to cart
	STEAM CONTROL VALVE ASM P136809750 Add to cart
	VALVE SAFETY 100# S/S P764316742 Add to cart
	VALVE SAFETY ½ IN. P764323459 Add to cart

PIPING COMPONENTS

Replace the air filter cartridge and rebuild the jacket trap.

AIR FILTER ASM-1/2 IN. NPT

P093909592

Add to cart

KIT STEAM TRAP REPAIR

P764080001

Add to cart

CONTROL

KIT FAN REPL CENT & EVOL

P755718039

Add to cart

SAFETY TESTING

Inspect the ground bond and connections to the sterilizer, including steam, water, and drain connections, and test ground continuity.

NEED HELP MAINTAINING THE STERIS EQUIPMENT AT YOUR FACILITY?

The STERIS Service team can help keep your equipment operating at peak performance to help reduce unnecessary downtime. Explore some of our service offerings below to learn more.

ConnectCare Remote Monitoring System

Equipment monitoring system that allows you to submit and manage service requests, generate summary reports, view operator manuals, and more to help reduce equipment downtime.

LEARN MORE

Equipment Care Plans

Flexible plans deliver the support you need to protect your investment and kepp your equipment running.

LEARN MORE

In-House Partnership Program

Delivers comprehensive, flexible tools and support to help your Biomed team succeed in maintaining STERIS equipment at the facility.

LEARN MORE

Why Buy STERIS Service Parts?

OEM Designed

Reliability Tested

90-day Warranty

STERIS OEM service parts are designed, tested, and approved to ensure reliable performance and maximize uptime.
All service parts purchased through STERIS are backed by a 90-day Warranty.

Technical Specifications

Page Title

TECHNICAL SPECIFICATIONS FOR AMSCO® CENTURY® SMALL STEAM STERILIZER

SPECIFICATIONS

OVERALL SIZE

16” Sterilizer	20” Sterilizer
600 mm wide x 1892 mm high x 908 mm deep	762 mm wide x 1892 mm high x 1146 mm
(26” wide x 74-1/2” high x 35-3/4” deep)	(30” wide x 74-1/2” high x 45-1/8” deep)

WEIGHT

Configuration	16” Sterilizer	20” Sterilizer
Single Door, Steam	340 kg (750 lbs)	558 kg (1231 lbs)
Double Door, Steam	449 kg (989 lbs)	728 kg (1606 lbs)
Single Door, Electric	404 kg (890 lbs)	622 kg (1371 lbs)
Double Door, Electric	n/a	782 kg (1726 lbs)

UTILITY REQUIREMENTS

ELECTRIC

Direct Steam:	240 V, 1.0 A, One Phase
Steam Generator:	240 V, 5.0 A, One Phase (control) (if equipped) 400 V, 65 A, Three Phase (heaters)

WATER

Specification	Sterilizer	Steam Generator
Pressure	2.1 to 3.5 bar (30 to 50 psig)	Steam Generator 1.4 to 3.5 bar (20 to 50 psig) (if equipped)
Temperature	Sterilizer 21°C (70°F) maximum	Steam Generator 60°C (140°F) maximum (if equipped)
Consumption	Sterilizer 23 lpm (6.0 gpm)	Steam Generator 23 Ipm (6.0 gpm) (if equipped)

STEAM

Configuration	16” Sterilizer	20” Sterilizer
Pressure	3.5 to 5.2 bar (50 to 80 psig)	3.5 to 5.2 bar (50 to 80 psig)
Consumption	38 kg/h (83 lb/hr)	53 kg/hr (116 lb/hr)

ENVIRONMENTAL CONDITIONS

Temperature	10° to 32°C (50° to 90°F)
Humidity	10 to 90% non-condensing
Pollution Degree	2
Installation Category (Overvoltage Category)	II
A-Weighted Sound Power Level	68 dBA (mean) -78 dBA (maximum)
